Quartz crystals depend on the piezoelectric outcome to function. It is based on a quartz resonator layered by an electrode on both sides after that mounted in a sealed holder. The function of an outside AC voltage toward these electrodes gives rise to mechanical vibration.

It is the capacitance of an oscillator circuit as offered to the quartz crystal resonator. The most ordinary kind of crystal is similar resonant somewhere the crystal functions at a frequency higher than its sequence resonant frequency.

Why not?! Say for instance a crystal is specified above –10 to +60°C it is going to perform with no issue above –40 to +85°C. However it might drop outside its particular stability. It may possibly not matter if the application requires only a steady frequency other than an exact frequency.

For quartz crystals think about the HC49/4HSMX and for oscillators (SPXO’s). Take a look at the CFPS-72/73 series. For any other products consult our help team as this can be dependant on performance.

The fundamental crystal oscillates on the frequency which is determined through the dimensions of the quartz blank. Overtone crystals function at moreover the 3rd, 5th, or 7th multiple of the primary. The crystal is particularly designed to work in these modes.
